Eclipse 5 Portable Oxygen Concentrator | Continuous Flow and Pulse Flow

Eclipse 5 Fishing
Eclipse 5 Groceries

Eclipse 5®

Transportable Oxygen Concentrator

The award-winning Eclipse 5 combines portability with clinical efficiency to adapt to your needs and accommodate a variety of activities – giving you the freedom to travel and enjoy life on the go. Suitable for use 24/7 use, this all-in-one oxygen therapy device delivers both continuous flow from 0.5 to 3 LPM (Liters Per Minute) and pulse doses up to a setting of 9.

** A prescription is required from your doctor to purchase this device. Call CAIRE for assistance. **

Visit our Travel & Safety page for information on traveling with your Eclipse 5.

SKU: 6900-SEQ Category: Tags: ,
Part Number: 6900BT-SEQ

Related products

Clinically-Effective Oxygen Delivery

Smart technology to ensure saturation

autoSAT® Automatic adjustment to patient’s respiratory rate
Adjustable Rise Time Maximizing inhaled oxygen
UltraSense® Sensitive breath detection technology
myCAIRE™ Telehealth solution

Continuous or pulse dose delivery to meet patients’ needs

With 6 continuous flow settings up to 3 LPM and 9 pulse flow settings up to 192 mL bolus, the Eclipse 5 serves a wide range of patients.

Unmatched Versatility and Ease of Use

Compact and Transportable

Only 18.7 lbs, with an easy-to-attach traveling cart with telescoping handle and durable wheels.

Extended Battery Life

Over 5 hours of battery life with ability to recharge while plugged into DC power at pulse setting 2.

Quiet

At 40 dBa the sound level is one of the quietest on the market.

Easy-to-Read Display

Large fonts and LCD display in LPM or mL for more accurate prescription verification.

Enables Airline Travel

FAA-approved for commercial airline travel.

24/ 7 Use

Meets a variety of needs for all phases of activity.

Proven Quality and Performance

Industry-Leading Reliability

Greater than 99% reliability rate out of the box.

Comprehensive Long-Term Warranty

CAIRE was the first manufacturer to offer a 3-year warranty on the device AND sieve beds.

Reduced Maintenance

Robust design features superior sieve bed technology reducing required maintenance.

Powerful Air Separation Technology

Vacuum Pressure Swing Adsorption (VPSA) is the most efficient way to deliver high purity oxygen.

Specifications

2 hours of battery at 2 LPM with single battery.

18.4 lbs. with battery.

Removable rolling cart with adjustable handle.

Runs on wall outlet (AC), motor vehicle (DC), or rechargeable battery power.

Included
  • Portable oxygen concentrator
  • Power cartridge (battery)
  • AC power supply
  • DC power supply
  • Removable cart
  • Accessory bag
  • Nasal cannula
  • Spare intake filter
Dimensions
  • Height: 19.3 inches
  • Width: 12.3 inches
  • Depth: 7.1 inches

Literature and Videos

Eclipse 5 Cutsheet (ML-CONC0148) ENG
FRE (ML-CONC0148-1) | GER (ML-CONC0148-2) | ITL (ML-CONC0148-5) | SPA (ML-CONC0148-3)  |  POR (ML-CONC0148-6)

Eclipse 5 Provider Folder (ML-CONC0216)
FRE (ML-CONC0216-1)  |  GER (ML-CONC0216-2)  |  SPA (ML-CONC0216-3)  |  ITL (ML-CONC0216-5)  |  POR (ML-CONC0216-6)

Eclipse 5 Provider Benefits (ML-CONC0221)
FRE (ML-CONC0221-1)  |  GER (ML-CONC0221-2)  |  SPA (ML-CONC0221-3)  |  ITL (ML-CONC0221-5)  |  POR (ML-CONC0221-6)

Eclipse 5 Smart O2 Features (ML-CONC0215)
FRE (ML-CONC0215-1)  |  GER (ML-CONC0215-2)  |  SPA (ML-CONC0215-3)  |  ITL (ML-CONC0215-5)  |  POR (ML-CONC0215-6)

Eclipse 5 Quick Start Guide (ML-CONC0062)
GER (ML-CONC0062-2)

Eclipse 5 User Manual (21182453) ENG
ENG, FRE, GER, SPA, ITL, POR, DUT, DAN, NOR, SWE, FIN, GRE, TUR, CZE, POL, HUN (21182453-C4)

Unboxing Video

Operation Video

Ref: ML-CONC0239 A
